Special model for mowing under low obstacles
|
The legendary SPIDER 2SGS series introduces the new SUPER LOW version – specially designed for areas with low obstacles. |
|
The SPIDER 2SGS SUPER LOW delivers productivity of up to 8,500 m²/h (2.1 acres/h). |
The SPIDER cutting system works on the principle of effective mulching, which eliminates the need to collect cut grass.
The mulch decomposes naturally, acting as a natural fertilizer for the soil.
The SUPER LOW model can handle grass up to 2.5 m (8.2 ft) high.
It is equipped with four rotary blades made of HARDOX® steel, combining strength and flexibility to withstand impacts with obstacles.
The blades are available in three designs – straight, curved, and profiled – for different vegetation types and mowing quality requirements.
Straight blades
A universal choice for most types of vegetation.
Provide even mowing and reliable performance even in dense grass.
Curved blades
The curved edge improves airflow and mulching quality.
Ideal for regularly maintained areas and shorter grass.
Profiled blades
The most versatile type, offering the best balance between performance and mulching quality.
Ensure a clean cut and excellent results even in taller vegetation.
Mowing under solar panels can be a real challenge.
The SUPER LOW model, with its remote control, all-direction drive system, and reduced profile, provides the perfect solution.
Based on the proven ILD02 and 2SGS models, it is approximately 20 cm (8 in) lower.
This makes it ideal not only for solar farms, but also for orchards, parks, and any areas where low machine height is an advantage.
|
The SPIDER 2SGS series is the only mower lineup on the market certified for mowing slopes up to 60°. |
|
Without a stabilization winch, the 2SGS SUPER LOW easily handles slopes of up to 41°. For steeper slopes or areas with lower traction, the machine is equipped with a safety winch, ensuring maximum safety while protecting the terrain. |
Power Unit
Kawasaki FS730V-EFI
25.5 HP/ 19 kW
Dimensions (l x w x h)
164 × 143 × 71 cm
Mowing width
123 cm
Speed
0 - 8 km/h
Mowing height
14 cm
Weight
360 kg
Selected mower
Drive unit
Kawasaki FS730V EFI
The Kawasaki FS730V EFI V-twin engine belongs to the latest generation of power units with electronic fuel injection (EFI) technology.
Thanks to precise fuel delivery, it maintains consistent power even in tall grass and on steep slopes.
Compared to the carbureted version, the EFI system ensures smoother operation and higher efficiency.
Engine Features:
Remote Control System
|
The SPIDER slope mower offers a remote control range of up to 100 meters (328 ft) and a controller battery life of up to 20 hours. |
|
The ergonomic remote control includes functions for: |
| starting and stopping the engine |
| adjusting the travel speed mode (turtle/rabbit) |
| engaging and disengaging the cutting deck |
| adjusting the cutting height |
| changing direction and speed |
| emergency shutdown |
Drive System
The SPIDER 2SGS mower moves smoothly and responds precisely to every movement of the joystick.
Both speed and direction can be finely adjusted, giving you full control at all times – even on slopes or in dense vegetation.
The ride is smooth, efficient, and safe.
Dancing Step
The patented drive system allows movement in all directions without the need to reverse.
Each wheel rotates independently by 360°, enabling the mower to change direction effortlessly, even in tight spaces.
We call this movement the “Dancing Step” – it’s what allows SPIDER to perform where other machines lose stability.
Skid Steering
SPIDER 2SGS mowers are equipped with a skid steering function, which enables the mower to rotate around its vertical axis, making maneuvering even easier.
Easy Transport
|
For transporting the mower, a special trailer for passenger cars can be used, featuring extendable ramps and a securing system to prevent the mower from shifting during transit. |
|
The compact dimensions of SPIDER mowers also allow for transport on standard trailers and in most utility vehicles. |
Power Unit |
| Engine | Kawasaki FS730V-EFI |
| Power | 25.5 HP / 19.0 kW (according to standard SAE J1995) |
| Displacement | 726 ccm |
| Ignition | electronic |
| Tank Capacity | 16 l |
| Fuel | unleaded gasoline |
Drive and Steering |
| Transmission | hydrostatic |
| Oil tank | 9 l |
| Speed | 0 – 8 km/h |
| Steering | 360°, 4 wheels |
| Drive wheels | 16 x 6.50-8 |
| Cutting width | 123 cm |
| Cutting height | 14 cm |
| Blade clutch | elektromagnetic |
Performance and Consumption |
| Work productivity | až 8 500 m2/h | |
| Fuel consumption | 3,8 l/h | |
|
60° (41° without the winch) | |
| Dimensions | 164 × 143 × 71 cm | |
| Weight | 360 kg |
|
We have reduced the number of painted components, as painting is an environmental burden, and peeling paint can pollute the surroundings over time. |
|
Up to 90% of our mowers are made from aluminum alloys, which are highly recyclable. |
|
The low fuel consumption of SPIDER mowers is the result of two main factors: an energy-efficient wheel chassis and a significantly lower machine weight, which is more than 70% lower than that of competing machines. These factors not only reduce fuel consumption but also directly contribute to lowering CO2 emissions. |
|
Our mowers are built for easy repairability and long service life—they can function effectively for over 10 years. This significantly reduces waste and decreases the need for new production. |
|
A single SPIDER mower can replace up to 16 brush cutters, meaning only one engine operates instead of 16, resulting in substantial emissions reduction. |
|
All manufacturing takes place in one location—in Pohled, Czech Republic. This minimizes transportation needs and lowers our overall carbon footprint. |
